Step 4 Step 4
A. Lift and place Right Junction Frame (B) onto Shaft Sleeve (163) and
secure using:
Four 54 (M8x12 allen head)
Four 86 (M10 at washer)
B. Lift and place Left Junction Frame (B) onto Shaft Sleeve (163) and
secure using:
Four 54 (M8x12 allen head)
Four 86 (M10 at washer)
12
