Step 8 Step 8
A. Connect Upper Console Wire and Heart Rate Wires to the back of
Console (15).
NOTE: The single Heart Rate ground spade connector is connected to the left
of the red console harness. Ensure that all wires are secure inside
console. Be careful not to pinch wires.
B. Secure Console (15) to Upright (F) using:
Four 63 (M5x12 phillips pan head bolt)
NOTE: The four Console Screws are located in the Step 8 hardware bag.
