Step 9 Step 9
A. Connect the harness on Handle Bar (E) to the harness on Upright (F)
as shown.
B. Connect Handle Bar (E) to Upright (F) using:
Two 68 (M8x120 allen head bolt)
Four 86 (M8.4 washer)
Four 95 (M8 crown nut)
Two 69 (M8x75 allen head bolt)
Four 211 (M8 arc washer)
NOTE: Ensure that all wires are secure inside Handle Bar (E) and Upright (F).
Be careful not to pinch wires.
22
