Endurance T50 - Step 3: Console and Cable Connections

Be careful to assemble all components
in the sequence they are presented.
Note: Do not fully tighten bolts until the unit is completely assembled.
A. Slide Handle Bar (K) into Right Upright Post (F) and secure using:
Two 59 (M5x10 phillips head bolt)
Two 67 (M5.5 arc washer)
B. Slide the remaining Handle Bar (K) into Left Upright Post (G) and secure
using:
Two 59 (M5x10 phillips head bolt)
Two 67 (M5.5 arc washer)
C. Attach both Lower Handle Bars (J) to Main Frame (A) using:
Four 48 (M10x25 round allen head bolt)
 Six65(M10.5atwasher)
Two 70 (M10 nut)
Step 3
14
