PART# QTY DESCRIPTION
A 1 Main Frame
B 1 Undercarriage Plate
C 1 Motor Compartment Plate
D 1 Ramp
E 1 Ramp Support Bracket
F 1 Upright Post (R)
G 1 Upright Post (L)
H 1 Vertical Bar
J 2 Lower Handle Bar
K 2 Handle Bar
L 1 Rear Roller Assembly
M 1 Front Roller Assembly
P 1 Motor Cover Bracket (R)
Q 1 Motor Cover Bracket (L)
R 2 Support Tube
A1 1 Lower Cable
A2 1 Lower Cable
B1 1 Shroud Cable
B2 1 Upright Post (R) Cable
C1 1 Shroud Cable
C2 1 Upright Post (R) Cable
D1 1 Shroud Cable
D2 1 Upright Post (L) Cable
PART# QTY DESCRIPTION DIMENSION
12 1 Safety Key
13 1 Complete Console
14 1 Motor Cover
15 2 Side Rail
17 1 Rear End Cap (L)
18 1 Rear End Cap (R)
21 1 Ramp Non-Slip Cover
22 2 Handle Bar Foam f40 x t3.0 x 1455mm
23 2 Upper Handle Bar Foam f36 x t3.0 x 165mm
24 1 Vertical Bar Foam f26 x t3.0 x 660mm
25 2 Handle Bar Cover (L)
26 2 Handle Bar Cover (R)
27 2 Double Sided Tape
28 1 Motor Belt 180 - J6
29 4 Leveller
30 6 Running Deck Cushion
Part numbers are required when ordering parts.
Complete Hardware List
