Assembly Hardware List (Steps 1 - 5)
Part numbers are required when ordering parts.
36
PART# QTY DESCRIPTION
A 1 Main Frame
F 1 Upright Post (R)
G 1 Upright Post (L)
H 1 Vertical Bar
J 2 Lower Handle Bar
K 2 Handle Bar
A1 1 Lower Cable
A2 1 Lower Cable
B1 1 Shroud Cable
B2 1 Upright Post (R) Cable
C1 1 Shroud Cable
C2 1 Upright Post (R) Cable
D1 1 Shroud Cable
D2 1 Upright Post (L) Cable
PART# QTY DESCRIPTION DIMENSION
12 1 Safety Key
48 8 Round Allen Head Bolt M10 x 25
51 1 Round Allen Head Bolt M8 x 15
54 4 Allen Head Bolt M8 x 10
55 4 Round Allen Head Bolt M8 x 30
59 8 Phillips Head Bolt M5 x 10
65 14 Flat Washer M10.5
66 6 Flat Washer M8.5
67 8 Arc Washer M5.5
70 6 Nut M10
71 4 Nut M8
93 1 Upper Console Shroud
112 1 Round Allen Head M8x45
