3.2 Door Position
The ventilator can be oriented in multiple positions.
Acceptable ventilator orientations are shown in Fig 3.
The BEFx can be installed indoors and outdoors without any
modications.
Wherever the ventilor is installed, make sure there is space
enough to be able to open the access door to an angle of
approximately 90°, as shown in Fig 4, and to access the
locking screws.
Fig 4
