ENFORCER SK-1123-SPQ User Manual

*SK-1123-SPQ only
5
ENFORCER Vandal Resistant Access Control Keypads
SECO-LARM U.S.A., Inc.
Features:
Specications:
Operating voltage 12~24 VAC/VDC
Current draw
(at 12VDC)
Standby 66mA
Keypress 93mA
Output 1 active 99mA
Output 1 & 2 active 126mA
Total max current draw 160mA
Outputs
#1 – Form C 1A@30VDC
#2 – Form C 1A@30VDC
Key active 100mA@24VDC
Duress 100mA@24VDC
Interlock 100mA@24VDC
Tamper 50mA@24VDC
Inputs
Egress N.O. Ground
Door sensor N.C. Ground
Door inhibit N.O. Ground
Proximity reader frequency* 125kHz (EM125)
Proximity reader sensing distance*
1½” (38mm)
Operating temperature -4°~158° F (-20°~70° C)
Operating humidity 5~95% Non-condensing
IP Rating IP66
Housing material Die-cast aluminum, powder paint coating
Dimensions (including back box)
4⁄”x3⁄”x2⁄” (125x79x52 mm)
Weight 1-lb 2-oz (520g)
• Built-in proximity card reader*
• 12~24 VAC/VDC Auto-adjusting operation
• Up to 1,000 possible user codes (000~999)
and/or proximity cards* programmable for
output #1, 100 (001~100) for output #2
• Up to 50 (01~50) possible temporary visitor
codes, which can be programmed for one-
time or limited-time use (1~99 hours)
• Output #1: Form C relay, 1A@30VDC max.
• Output #2: Form C relay, 1A@30VDC max.
• Outputs #1, #2 can be programmed to
activate for up to 99,999 seconds
(nearly 28 hours)
• Tamper output: N.C. Dry contact,
50mA@24VDC max.
• IP66 Weatherproof Rating
• Mounts to a standard single-gang back box
(surface-mount back box included)
• Keypad illuminates when a button is pressed;
backlight can be programmed for FULL,
AUTO, or OFF in standby mode
• All features are programmed directly from the
keypad: No need for an external programmer
• EEPROM Memory protects programmed
information in case of power loss
• Up to 50 (01~50) duress codes for output #1,
10 (01~10) for output #2
• Duress code signals a silent alarm if an
authorized user is forced to open the door
under duress
• Egress input lets users exit the premises
without keying in the code
• Door sensor input for anti-tailgating operation
• Interlocking input for connecting to a second
keypad
