ENFORCER SK-1323-SPQ User Manual

ENFORCER Outdoor Stand-Alone Keypads
2 SECO-LARM U.S.A., Inc.
Features
Table of Contents
Specifications
 12~24 VDC/VAC operation.
 1,010 User codes.
 2 Form C relays, each rated 1 Amp @ 30VDC.
 Each relay has programmable output time
from 1~99 seconds or toggle.
 Output #2 can be programmed for use
with a doorbell.
 2 Egress inputs and 1 door sensor input.
 Backlit keys for easy nighttime use.
 Able to mount to a single-gang back box.
Operating voltage
12~24 VDC/VAC
Current draw
Standby
64mA@12VDC
1 Relay active
92mA@12VDC
2 Relays active
120mA@12VDC
Relay outputs
Output #1
1A@30VDC, Form C, NO/NC/COM
Output #2
1A@30VDC, Form C, NO/NC/COM
Egress inputs
Input #1
N.O. ground
Input #2
N.O. ground
Door sensor input
N.C. ground
Tamper sensor
Optical
Operating temperature
-4°~122° F (-20°~50° C)
Keypad LED life
60,000 hours (over 6.8 years)
Weight
SK-1323 Series
1-lb 2-oz (510g)
SK-2323 Series
11-oz (312g)
Proximity reader frequency
SK-2323-SPQ and SK-1323-SPQ only)
125kHz
Proximity reader distance
(SK-2323-SPQ and SK-1323-SPQ only)
2” (5cm)
Sample Wiring and Application ................. 6-7
User Control Chart ..................................... 8-9
Programming Instructions ...................... 10-13
Resetting the Keypad .................................. 14
Manually Resetting the Master Code .......... 14
Factory Defaults .......................................... 14
Using the Keypad ........................................ 15
Troubleshooting .......................................... 15
Quick Reference Guide ............................... 16
Warranty ..................................................... 16
Features ........................................................ 2
Specifications ................................................ 2
Also Available from SECO-LARM ................. 2
Dimensions.................................................... 3
Parts List ....................................................... 3
LED & Audible Indicators .............................. 3
Optical Tamper .............................................. 3
Important Notes ............................................. 4
Wiring Diagram.............................................. 4
Installation ..................................................... 5
 All features are programmed directly from the
keypad—no need for an external programmer.
 EEPROM memory protects programmed
information in case of power loss.
 Optical tamper for added security.
 Circuitry is potted with epoxy for outdoor use.
 IP 65 weatherproof rating, rugged aluminum
construction.
 Built-in proximity card reader
(SK-2323-SPQ and SK-1323-SPQ only).
Also Available from SECO-LARM
PR-K1S1-A: Proximity cards.
(Sold in packs of 10).
PR-K1K1-AQ: Proximity key fobs.
(Sold in packs of 10).
