EngA CenCon User Manual

CenCon
43
H4a
DO
Heating stage #
4
Output stage #4 heat
ing, powered from common ‘a’.
24/120 Vac
CMb COM
Common to
output set ‘b’
Common power relays ‘b’.
24/120 Vac
H5b
DO
Heating
stage #
5
Output stage #5 heat
ing, powered from common ‘b
’.
24/120 Vac
CMc COM
Common to
output set ‘c’
Common power relays ‘c’.
24/120 Vac
H6c
DO
Heating stage #
6
Output stage #6 heat
ing, powered from common ‘c
’.
24/120 Vac
CMd COM
Common to
output set ‘d’
Common power relays ‘d’.
24/120 Vac
H7d
DO
Heating stage #
7
Output stage #7 heat
ing, powered from common ‘
d
’.
24/120 Vac
DSw
DI
Door Switch
External safeties input.
24/120 Vac
HLN
High limit
neutral
External safeties input neutral.
24/120 Vac
HL
DI
High Limit
Normally closed, opens on high temperature.
24/120 Vac
STAGED HEATING
Inter-stage timing is non-adjustable, however the timers may be truncated on initial startup depending on the
level of temperature demand.
HIGH AMBIENT LOCKOUT
Electric heating is disabled above the design high ambient lockout setpoint.
