6 Maintenance
EC209
Fastener
Dimension
Quality
Quantity
Torque
Screw cap
M12
12.9
8
136 Nm
Quick hitch
M14
12.9
12
217 Nm
Yoke bracket
M16
12.9
8
333 Nm
Tilt axle
M16
12.9
8
333 Nm
Clamping half
M10
12.9
8
79 Nm
Hydraulic motor
M12
12.9
2
136 Nm
Table 12.
EC214
Fastener
Dimension
Quality
Quantity
Torque
Screw cap
M12
12.9
8
136 Nm
Quick hitch
M16
12.9
12
333 Nm
Yoke bracket
M16
12.9
8
333 Nm
Tilt axle
M16
12.9
14
333 Nm
Clamping half
M10
12.9
8
79 Nm
Hydraulic motor
M12
12.9
2
136 Nm
Table 13.
EC219
Fastener
Dimension
Quality
Quantity
Torque
Screw cap
M12
12.9
8
136 Nm
Quick hitch
M20
12.9
12
649 Nm
Yoke bracket
M16
12.9
8
333 Nm
Tilt axle
M16
12.9
14
333 Nm
Clamping half
M12
12.9
8
136 Nm
Railway grab, grab
axle
M20
12.9
2
649 Nm
Hydraulic motor
M12
12.9
2
136 Nm
Table 14.
