6 Maintenance
EC226
Fastener
Dimension
Quality
Quantity
Torque
Screw cap
M14
12.9
8
217 Nm
Quick hitch
M20
12.9
12
649 Nm
Yoke bracket
M16
12.9
8
333 Nm
Tilt axle
M16
12.9
18
333 Nm
Clamping half
M20
12.9
8
136 Nm
Railway grab, grab
axle
M20
12.9
2
649 Nm
Hydraulic motor
M12
12.9
2
136 Nm
Table 15.
EC233
Fastener
Dimension
Quality
Quantity
Torque
Screw cap
M12
12.9
12
136 Nm
Quick hitch
M20
12.9
20
649 Nm
Yoke bracket
M16
12.9
8
333 Nm
Tilt axle
M20
12.9
16
649 Nm
Clamping half
M14
12.9
8
217 Nm
Railway grab, grab
axle
M20
12.9
2
649 Nm
Hydraulic motor
M12
12.9
2
136 Nm
Table 16.
EC-Oil hydraulic connectors
Type
Fastener
Quantity
Torque
ECO45/50/60/70
Hydraulic connector
ECO
2
60 Nm
Table 17.
49
