Engel MT60F-U1 - Dimensions (MT60 F-U1; MT80 F-U1-S)

■ Dimensions (MT60F-U1 / MT80F-U1-S)
Unit (mm)
※ Tolerance is omitted
1. SPECIFICATIONS
2
370
520 (MAX.OUTSIDE)
610
640
790
802 (MAX. OUTSIDE)
441 ((MT60F) MAX. OUTSIDE) 561 ((MT80F) MAX. OUTSIDE)
420 (MT60F)
/ 540 (MT80F)
490
517(MT60F)
514(MT80F)
315(MT60F) 375(MT80F)
378(MT60F) 410(MT80F)
