■ Dimensions (MT60F-U1-C)
Unit (mm)
※ Tolerance is omitted
1. SPECIFICATIONS
3
370
520 (MAX.OUTSIDE)
610
640
790
802 (MAX. OUTSIDE)
441
42
490
260
315
205
315
400
378
