INSTALLATION INSTALLING THE DEVICE
2-3
5. Plug the other end of the Ethernet cable into the PoE port
of the PoE injector.
Figure 2-1: Installing the ENS500
6. Turn over the ENS500. Then insert the pole mounting
strap through the middle hole of the ENS500. Use a
screwdriver to unlock the pole-mounting ring putting it
through the ENS500.
7. Mount the ENS500 securely to the pole by locking the
strap tightly.
This completes the installation procedure.
