IQ 7 / IQ 7+ / IQ 7X / IQ 7A Micro Installation and Operation
© 2020 Enphase Energy Inc. All rights reserved. 141-00043-03
13
Enphase Microinverter Installation
Installing the Enphase IQ Series Micros involves several key steps. Each step listed here is detailed in
the following pages.
Step 1: Position the Enphase Q Cable
Step 2: Position the Enphase Q Aggregator or Junction Box
Step 3: Mount the Microinverters
Step 4: Create an Installation Map
Step 5: Manage the Cabling
Step 6: Connect the Microinverters
Step 7: Terminate the Unused End of the Cable
Step 8: Complete Installation of the Enphase Q Aggregator or Junction Box
Step 9: Connect the PV Modules
Step 10: Energize the System
Junction box
Enphase
IQ Series
Micros
Tie wraps
or cable
clips
DC
connectors
AC
connector
Enphase Q
Cable
Terminator
Horizontal mount
> 300 mm
Vertical mount
