IQ System Controller 2 Quick Install Guide
Plan a location for the
IQ System Controller 2
Mounting the product
Section A
• IQ System Controller 2 is NEMA type 3R rated and can be mounted both
indoors and outdoors. Install the unit where it is not exposed to direct rainfall.
• Install this product where cables from PV/IQ Combiner, grid, and IQ Battery
are easily accessible and can be terminated at the IQ System Controller 2.
• This product is designed to be installed on a vertical wall only.
Do not install this product at on the ground.
• The mounting surface must support 87 lbs.
• Follow all local standards and regulations during installation.
• The product operates within an ambient temperature range from -40°C to 50°C.
• Do not install this product in a place directly exposed to sunlight.
• Do not install the product in a dusty environment.
• This product must not be installed at altitudes above 8,200 ft (2,500 m).
• In ood-prone areas, ensure that the clearance from the ground is sucient
to avoid water ingress.
-40°C
+50°C
