IQ8 Commercial Microinverter grid-tied PV system
71 © 2023 Enphase Energy Inc. All rights reserved. November 2023
USG-00026-1.0
UV resistance 720 h
Compliance Type DG, THHN/THWN-2, UL3003
Minimum bending radius R = 4 × OD
Cable dimensions Diameter 11.5 mm
Sealing Cap dimensions 28×60×23
Cable Connector dimensions 82×60×18
10.3 IQ Gateway Commercial 2
Enphase IQ Gateway Commercial 2 ENV2-
IQC2-AM3-3P
Three-phase communications gateway with
integrated, revenue-grade PV production metering
(+/- 0.5%) and optional consumption monitoring
(+/- 2.5%). Includes three 400 A continuous-rated
production CTs.
ACCESSORIES (order separately)
Enphase Mobile Connect
o CELLMODEM-M1-06-SP-05
o CELLMODEM-M1-06-AT-05
Plug-and-play industrial grade cellular modem with
a five-year data plan (expandable to 12 years).
Available in the US, Canada, Mexico, Puerto Rico,
and the US Virgin Islands, where there is adequate
cellular service in the installation area.
Consumption Monitoring CTs
CT-600-SPLIT
(Order three or six, as needed)
Split-core current transformers enable
consumption metering.
POWER REQUIREMENTS
Power requirements
208Y/120 VAC three-phase
220Y/127 VAC three-phase
Max 20 A overcurrent protection is required
CAPACITY
Number of microinverters polled Up to 275
MECHANICAL AND ELECTRICAL DATA
Dimensions (W×H×D)
21.3 × 12.6 × 4.5 cm (8.4" × 5” × 1.8")
Weight
17.6 oz (498 g)
Ambient temperature range
-40° to 65°C (-40° to 149°F)
-40° to 46°C (-40° to 115°F) if installed in an
enclosure
Environmental rating
IP30. For installation indoors or in an NRTL-
certified, NEMA-type 3R enclosure.
