enphase IQ8H-3P-72-E-US User Manual

IQ8 Commercial Microinverter grid-tied PV system
72 © 2023 Enphase Energy Inc. All rights reserved. November 2023
USG-00026-1.0
Altitude
Up to 2000 m (6,560 feet)
Production CTs
o Capable of measuring 400 A of continuous current
with 1.0% accuracy
o Accuracy of +/-0.5% for revenue grade production
metering (ANSI C12.20 certified)
o Internal aperture measures 43 mm to support up to
a maximum size of 1000 KCMil conductors
o
UL2808 certified
INTERNET CONNECTION
OPTIONS
Integrated Wi-Fi
Integrated Wi-Fi
Ethernet
Ethernet
Mobile
Optional, CELLMODEM-M1-06-SP-05 or
CELLMODEM-M1-06-AT-05, not included
COMPLIANCE
Compliance
o UL 916
o CAN/CSA C22.2 No. 61010-1 47 CFR, Part 15, Class B, ICES 003
o IEC/EN 61010-1:2010
o EN50065-1, EN61000-4-5, EN61000-6-1, EN61000-6-2 ANSI C12.20
o
NoM
11 Appendix D: Photovoltaic Hazard Control System
To enable the installed system as a Photovoltaic Hazard Control System (PVHCS), perform the following
tasks.
Before installing or using the Enphase microinverter in a system, read all instructions and cautionary
markings in the technical descriptions on the Enphase equipment and all other photovoltaic (PV)
equipment.
11.1 Photovoltaic Hazard Control System (PVHCS), System
equipment
Inverter
Enphase Models IQ8P-3P-72-E-US/IQ8H-3P-72-E-US UL Listed to all current UL1741
requirements, including PV rapid shutdown (PVRS).
PV modules
The inverters used in this PV Hazard Control system shall be connected to up to two series-
connected PV modules with a maximum DC Input voltage of no greater than 119V under any
circumstances. The installation location's coldest anticipated operating ambient needs to be used
to calculate the PV maximum voltage in accordance with NEC 690.7. The PVHC PV modules must
