9
5 Package Contents
Device
1671901 Eltrac 471
Standard accessories Eltrac 471:
1471800 Patient stop switch
1471801 Fixing knobs, set of 4
1471806 Nylon cord 170 cm with carabiner hook
1671751 Operating Instructions Eltrac 471
3444290 Power cord
6 Installation
6.1 Connection to mains supply
Insert the mains cable into socket [5] and connect it to a wall socket.
!
!!
!
CAUTION:
• Do not place the device in a location where the power cord could be tripped over or pulled out
during treatment.
• Do not attempt to use the device if it is not properly grounded. Make certain that the device is
electrically grounded by connecting it only to a grounded electrical service receptacle
conformable with the applicable national and local electrical codes regarding medical
environments.
Turn on the device with push button [4]
The device will initialize and perform a self-test. This may take a while.
At the end of the self-test the device enters the Home menu and is ready for use.
6.2 Disconnection from mains supply
Turn off the device with push button [4]
6.3 Attachment carabiner hook
!
!!
!
CAUTION:
The cord must be attached to the carabiner hook by means of a knot capable of withstanding
considerable traction, without coming undone. A suitable knot is shown in the figure below.
