9
With the bases in their desired location, slightly loosen both legs to
allow the strap to fit on the leg bolt, between the leg washer and
frame.
Slide side (a) of the connecting strap onto leg bolt. Swing the
strap and connect side (b) to the leg bolt. Secure the strap by
shifting to the left.
Re-tighten legs. Do not over tighten. Use the remaining strap and
repeat on other end of the base.
STEP 2
STEP 1
STEP 3
connecting strap (optional)
a
b
If a split setup is being installed, optional plastic connecting straps can be used to help secure the bases
together. To purchase optional accessories, please call 1-844-534-3676.
