Enso PB475 - Quick Reference Guide; Electronics Diagram and Connections; Control Box Removal Instructions

6
quick reference guide
Not to scale. For illustration purposes only. Read all instructions before beginning installation.
ELECTRONICS OVERVIEW
If installing a split unit - see page 10.
Power Cord (D)
Power Supply (E)
Head Motor Foot Motor
Control Box
Input
Power Cord
To remove control box, release
metal clip and unplug cords.
Powerdown
Box Port
Input Cord
Connection
Power LED
Light
Head Motor
Port
Foot Motor
Port
Wireless
Remote
