Enviro C60 - OPTIONAL STEP Cool Surface System Part 3

OPTIONAL STEP Cool Surface System Part 3
Venting Clearances - Front Vent
Shown here are the minimum framing and clearances for
the CSS when the replace is installed with the minimum
allowable vent length:
Min. Ceiling Clearance from top of CSS outlet = 4” (10.2 cm)
Min. Ceiling Clearance in wall from top of CSS Body = 5
5
/
8
” (14.3 cm)
CSS Body Min. Rear stando = 2¾” (69.8 cm)
5
5
8
" (14.3 cm)
4" (10.2 cm)
2
3
4
" (69.8 cm)
73
1
4
"
(174.9 cm)
Side Brace
Min. Height
20" (50.8 cm)
Min. Depth
39” (99 cm) Min.
Length 5” dia. ex vent
(not supplied)
80” (203 cm)
C34/44/60 Min. Ceiling
Min. Vent
82 3/8”
(212 cm)
Side Brace
Min. Height
91” (231 cm)
C72 Min. Ceiling
C34
C44
C60
C72
Venting Clearances – Side Vent
CSS Horizontal Vent - Min. Framing & Clearances CSS Vertical Vent - Min. Framing & Clearances
15.00” (38cm)
11.50”
(29cm)
Min. Height
to Ceiling
14.50
Min. Height
66.00”
(168cm)
Min. to
Ceiling
5” (12.5cm)
Min. Height
from oor
69.5” (176.5cm)
39” (99 cm) Min.
Length 5” dia. ex vent
(not supplied)
Min. Vent
Min. Distance to
wall from standoff
5.00” (13cm)
Min. Ceiling
Height
18.75”
(48cm)
*15.75” (40cm)
11.5” (29cm)
Min. Dist
61.75”
(157cm)
*NOTE: 15.75” from the
header is required for min.
ceiling height. Rest unit on
lower standoff. There will be
a 3/4“ (2cm) gap on from
the top standoff to the
header in this confirguration.
Min Framing is 15” x 11.5”
3/4” (2cm)
Gap Shown
Min. Distance
to Ceiling
4.5” (11.5cm)
Min. Distance
to oor
64” (162.5cm)
39” (99 cm) Min.
Length 5” dia.
ex vent
(not supplied)
