Enviro EF-II I - Stove Removal From Pallet; Dimensions

REMOVING YOUR NEW STOVE FROM IT’S PALLET
To remove your new stove from its pallet, open the left and right side panels. There are two wood screws that are
holding the bottom of the stove to the pallet. Remove the screws. Close the side panels. See PAGE 18 how to
install the pedestal.
INSERT MODEL FREESTAND MODEL
REMOVE SCREW HERE
DIMENSIONS
13
30.5”
24”
22”
SURROUND
PANEL
11 ½”
