MODEL FS (FREESTANDING) INSTALLATION
PEDESTAL INSTALLATION
Model FS comes with a pedestal that has to be attached prior to
installation:
- Remove the pedestal from the box
- Remove the ENVIROFIRE unit from the box
- Place the unit on its back, making sure not to
damage the wiring.
- Back off the screws on the base, install the
pedestal over the screws.
- Lock pedestal in place using the keyholes,
tighten the screws. Return unit to upright.
INSTALLATION
KEYHOLES
18
