Enviro Mini A Technical Manual

11
Figure 13: Corner Installation.
CORNER THROUGH WALL INSTALLATION:
3" (75mm)
3"
(75mm)
Wall thimble
manufactured
by pellet vent
manufacturer.
Installation
MOBILE HOME INSTALLATION:
ENVIRO Mini
1
/4” Lag Bolts
Securely Fastened
Ground Wire Directly
to Metal Chassis
Optional
Hearth Pad
Flooring
Steel Frame
● Secure the heater to the floor using the
two holes in the pedestal.
● Ensure the unit is electrically
grounded to the chassis of your home
(permanently).
● Do not install in a room people sleep
in.
● Outside fresh air is mandatory. Secure
outside air connections directly to
fresh air intake pipe and secure with
three (3) screws evenly spaced.
CAUTION
: THE STRUCTURAL
INTEGRITY OF THE
MANUFACTURED HOME FLOOR,
WALL AND CEILING/ROOF MUST
BE MAINTAINED.
Figure 12: Mobile home installation.
