Enviro VDD User Manual

ENVIRO-TEC
11
FORM ET115.24-NOM12 (718)
Clearance
All units, including those with electric heat, are listed
for zero clearance to combustibles.
Sufficient clearance for normal servicing of this
equipment is recommended.
All electrical panels must have 36” working space in
front of panel to meet National Electric Code; however,
local inspectors may wave this requirement if the hinged
cover has a 90° free swing.
FIELD WIRING
Prior to installing any wiring, check
the unit name plate for main power
voltage, control voltage, transformer
sizing and any fuse sizing. All eld
wiring must comply with National
Electric Code and local code require-
ments.
TABLE 1: UNIT WEIGHT DATA (LBS./KG)
COMPONENT
UNIT SIZE
08 12 16 20
30 (SINGLE
BLOWER)
40 (SINGLE
BLOWER)
30 (DUAL
BLOWER)
40 (DUAL
BLOWER)
BASE UNIT 115 [52] 133 [60] 152 [69] 175 [79] 287 [130] 305 [139] 357 [162] 375 [170]
MIXING BOX 46 [21] 54 [25] 65 [30] 90 [41] 105 [48] 105 [48] 162 [74] 162 [74]
BLOW THRU ELECTRIC
HEATER
42 [19] 42 [19] 55 [25] 55 [25] 55 [25] 125 [57] 55 [25] 125 [57]
COIL
ROWS
1 ROW - DRY 12 [5] 14 [6] 17 [8] 21 [10] 26 [12] 26 [12] 32 [15] 32 [15]
1 ROW - WET 14 [6] 16 [7] 20 [9] 25 [11] 32 [15] 32 [15] 41 [19] 41 [19]
2 ROW - DRY 17 [8] 21 [10] 26 [12] 33 [15] 42 [19] 42 [19] 52 [24] 52 [24]
2 ROW - WET 21 [10] 26 [12] 32 [15] 42 [19] 54 [24] 54 [24] 69 [31] 69 [31]
3 ROW - DRY 23 [10] 28 [13] 35 [16] 45 [20] 57 [26] 57 [26] 72 [33] 72 [33]
3 ROW - WET 29 [13] 36 [16] 44 [20] 59 [27] 75 [34] 75 [34] 95 [43] 95 [43]
4 ROW - DRY 29 [13] 35 [16] 44 [20] 57 [26] 73 [33] 73 [33] 91 [41] 91 [41]
4 ROW - WET 37 [17] 45 [20] 56 [25] 74 [34] 96 [44] 96 [44] 121 [55] 121 [55]
6 ROW - DRY 40 [18] 49 [22] 62 [28] 81 [37] 104 [47] 104 [47] 132 [60] 132 [60]
6 ROW - WET 52 [24] 64 [29] 81 [37] 106 [48] 138 [63] 138 [63] 178 [81] 178 [81]
Tighten all wiring lugs and terminals prior to
connecting power to the unit, as they may loosen during
transportation.
Route the power lines to the power distribution
terminals inside the control enclosure. If a factory wired
disconnect switch is installed, then connect the power
lines to the line side of the switch.
Mount and wire any eld installed items as indicated on
the factory supplied wiring diagram. When mounting
eld installed components, do not jumper out or rewire
any factory wiring without written approval from
ENVIRO-TEC. Violation will void warranty.
NOTES:
1. Unit weight data is shipping weight in pounds [kilograms].
