Enviro WINDSOR User Manual

12
27
1
/8"
(689mm)
25
3
/4"
(653mm)
25
7
/8"
(659mm)
15
3
/8"
(390mm)
14
1
/4"
(360mm)
24
1
/8"
(614mm)
Installation
DIMENSIONS:
Figure 6: Windsor Freestanding Dimensions.
Back wall
Side wall
Adjacent
wall
3"
(76mm)
3" (76mm)
8"
(203mm)
6"
(152mm)
Floor Protection
Figure 7: Minimum Clearances to Combustibles for
Freestanding Windsor.
CLEARANCES TO COMBUSTIBLES:
These dimensions are minimum clearances but it
is recommended that you ensure sufficient room
for serving, routine cleaning and maintenance.
This pellet stove requires floor protection. The
floor protection must be non-combustible,
extending beneath the stove the full width and
depth of the unit including 6“ (150 mm) in front
for ember protection.
Hearth Pad Size:
Width: 25 ” (651 mm)
Depth: 32  “ (816 mm)

Enviro WINDSOR Specifications

General

Hopper Capacity	60 lbs
Ignition	Automatic
Thermostat	Yes
Fuel Type	Pellet
Venting	3" or 4"
