EOGB BTL 0 - Recommended Nozzles

ONE STAGE LIGHT OIL BURNERS
12 / ...
000608....._2006/09
NOTE:
The values repoted on this table are referred at the 12% CO
2
at the mean sea level and with 0.1 mbar pressure in the
combustion chambre.
NOTE:
The values indicated in the table are purely indicative; for best burner performance adjustment needs to be made in
accordance with the demands of the particular boiler type.
RECOMMENDED NOZZLES
Delavan type W 45°
Delavan type W 60°
Danfoss type S 45°
Model
Adjustment data
Nozzle
type
Pump Burner
flow rate
3
Air gate
adjustment
2
Disk position
adjustment
GPH bar kg/h n° tacca n° tacca
BTL 0 1.00
12
4,20 7 5
0,85 3,50 6,5 3,5
0,75 3,00 5 3
0,60 2,40 4 2
0,50 2,00 3,5 0,5
BTL 4 1,25
12
5,00 6,5 5,5
1,10 4,70 6 5
1,00 4,20 5,5 4
0,85 3,60 4,5 3,5
0,75 3,10 4 2,5
0,60 2,50 3 1
BTL 6 1,65
12
6,50 6,5 5
1,50 6,10 6 5
1,35 5,60 5,5 3,5
1,25 5,00 5 3
1,10 4,70 4,5 3
1,00 4,20 4 2,5
0,85 3,60 3 2
0,75 3,10 3 1
BTL 10 2,25 12 9,20 7 6
2,00 8,50 7 5
1,75 7,30 6,5 4
1,50 6,10 5 3
1,35 5,60 5 2,5
