EOGB BTL 0 - Standard Accessories; Operating Range

ONE STAGE LIGHT OIL BURNERS
6 / ...
000608....._2006/09
*) Total absorption at start with ignition transformer on. de encendido conectado.
MODEL BTL 0 BTL 4
BTL 6 BTL 10
Burner output
min kg/h 1,80 2,20
2,70 5,10
max kg/h 3,6 4,7
6,3 10,0
Thermic capacity
min kW 21,3 26,0
31,9 60,2
max kW 42,7 56,1
74,3 118,0
Fuel max. viscosity
5,5 cst / 20° C
1,5° E / 20° C
“Electrical feeding 1 ~ 230V ±10% - 50Hz
Motor kW 0,10
Tranformer
40 mA - 15 kV
Absobed electrical power *) KW 0,150
Weight kg 12
Operation ON / OFF
OPERATING RANGE
N° 0002922250
Rev. 15/05/01
n° 1 Isolating gasket
n° 1 1/4” x 1/4” x 1200 exible hoses
n° 4 M8 at washer
n° 5 Exagonal nuts M8
STANDARD ACCESSORIES
n° 4 TE M8 x 37 screws
n° 1 M8 x 25 screw
n° 2 1/4” nipples
