INSTALLATION
Install the unit
After inserting the holder into the dash-board,select the appropriate tabs according to the
thickness of the dash-board material and bend them.(Install as firmly as possible using the
top and bottom tabs. To secure, bend the tabs 90 degrees.)
Insert the keys supplied to the unit at both sides of the unit (shown as illustrated)until
they click. Pulling the keys makes it possible to remove the unit from the dashboard.
38
