The acquired colour is displayed on the monitor as a guide only. It is very likely that it will appear
to be different from the actual colour of the sample. This is due to several factors (such as the
ambient light, monitor calibration, gamma settings) which must be controlled and fine tuned
for the colours to match.
In the Colour Classification interface, the user can select up to 5 colours from the References list. The selection can be
made by dragging the colours from the References list to one of the five sections in the Reference colour display area
. These colours will set the classes to which the measured sample may belong. The colours can be removed by
clicking on the remove button .
Once a Measure is available (either just acquired or selected by double-clicking in the Measure list), the Colour
Classification engine will identify the class to which the Measure belongs and place the Classification Result indicator
next to the corresponding Reference colour. The E*
ab
difference between the Measure and each Reference is also
shown .
If the difference between the Measure and all the classes exceeds the set maximum threshold , the Measure is not
assigned to any class. In this case the classification result indicator is removed xt to
the Maximum Threshold selector .
