Indicator status description
Indicator
Status
Description
Eoptis
OFF
system not powered or not recognised by host PC
Red steady ON
system powered and correctly recognised by host PC
M
Green steady ON
system in Measure mode (alternative to Reference mode)
R
Green steady ON
system in Reference mode (alternative to Measure mode)
ACQ
Red steady ON
colour acquisition in progress
OFF
ready for a new acquisition
Red Dimmed
waiting for next acquisition during Multiple Acquisition mode
Button operations
Button
Action
Description
Acquire (left)
Single click
triggers a new acquisition to start
Double click
enable/disable Multiple Acquisition mode
Function (right)
Single click
toggles between Reference and Measure mode
Double click
undo last operation
