EOS Cubo Assembly And Operating Instruction

24
EN
Assembly of the protective cover on the sauna heater
94 4707
54
27
2.
A
4x Ø 3,5
1.
299,5
4 plate screws for each
All plate screws for suspension of the heater protector.
All metric screws: for mounting the rocker switch
All dimensions provided in mm.
Detail A
Protective cover Typ 1
Art. Nr. 944421
Assembly-Set for
protective cover
Art. Nr. 944707
Lay the control cable for the rocker switch and heater supply
with a minimum clearance of 30 mm.
Control cable for
rocker switch
