38
39
Fig.9 Drive motor
1
2
3
4
5
6
7
8
9
0301415001
0301408001
4300900002
0301411001
2001420001
2001427002
0301412001
0301400002
0301400001
3
1
2
1
1
1
1
1
1
Tie-in
Plastic mantle
Screw
Cover
Bearing
Snapring
Spring
Rotor
Drive motor
Fig.8 Driving system
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Brake assembly
Spline
Snap ring
Sleeve
0-ring
Flat key
Moto r
Screw
Position sleeve
Dus t ring
O-ring
Bearing
Snap ring
Snap ring
Gea r
Semicircle key
Nu t
0301000001
2001021001
2001427001
4301412002
2000628005
2001021001
0301400001
0301431001
2001212003
2001405001
2001228001
2001420001
2001427001
2001227003
2000121005
2001435001
2001425002
1
1
1
1
1
1
1
4
1
1
1
1
1
1
1
1
1
