Fig. 4 图4 Fig. 5 图5
Fig. 6 图6
1.16 Parking
The truck should always be parked on a level surface, engaged with a parking brake. The forks must be
lowered to their lowest position, so that no one may accidentally trip over them. Always turn the ignition to the
“OFF” position and remove the ignition key from the electrical lock when leaving the truck.
If the truck is left unused for a prolonged period without it being recharged, the battery plug should be
disconnected.
1.17 Repair
Without professional training and specific authorization, the operator is forbidden to repair or change any
part of the truck. Any change of installation position of switches and safety devices is strictly forbidden by
operator to avoid efficiency decrease of the truck.
All spare parts from original manufacturer are qualified by Quality Assurance Authorities. To ensure the
safety and reliability of truck operation, only spare parts from manufacturer can be applied. The parts
replaced, including oils and fuels, must be disposed according to related environmental protection
regulations.
1.9 No unbalanced load or overload
An unbalanced load will lead to the goods fall off the ground or more severely the truck will turn over.
1.10 Speed
Adjusting the speed to the floor conditions, the line of sight and operational safety. Avoid fast acceleration,
rapid braking and cornering at speed, there is a risk for overturning or that the load may fall off.
Speed option is only available when protection arm is open.
1.11 Signaling
Use the signal horn to attract attention when make a turning.
1.12 Floor Load
Carefully check notices or directives about the max. floor load or max. wheel pressure to ensure that these
are not exceeded.
1.13 Smooth Travel
Drive the truck smoothly. Quick steering will be dangerous. Avoid sudden movement of controls. And always
remember to travel with forks at low position close to the ground.
1.14 Loaded travel/ unload travel
When operating loaded truck, keep the rear end of the truck pointed downhill. When operating unloaded truck,
keep the rear end of the truck pointed upgrade.
1.15 Driving on Slope
The cargo carried must face to upward direction of the slope.
Take safety measures to the downward slip direction of the truck: when control button at “ 0” position,
please pull the handle backwards immediately and release it according to actual requirement to enable the
electromagnetic brake to work automatically and control the speed and direction of truck (for downward slip).
2
3
2.Control Bar Assembly Instruction
(1) Screw off the bolts #1,#2,#3,#4,#5,#6
Warning: not to screw off the middle bolt #7
(2)Push the cover aside
(3) Join the wire connection #9
(4) Fix the cover back and tightening
The 6 pieces of bolts
