After the red light starts ashing,
the battery will enter the low-voltage
protection state. According to the battery
state, The truck will appear accidental
power-o protection. Please charge the
battery after restarting to avoid damage
to the battery.
NOTE
EPL152
If the controller detects a battery failure, ashes of LCD
（
1
）
represent battery failure information
until the failure is remedied. Details of failure information are shown as below:
Under-voltage of single cell battery: The green light repeats in a cycle of flashing once in 1
second, pausing for 2 seconds and then ashing twice, pausing for 3 seconds.
Over-voltage of single cell battery: The green light repeats in a cycle of flashing once in 1
second, pausing for 2 seconds and then ashing three times, pausing for 3 seconds.
Short circuit protection: The green light repeats in a cycle of ashing once in 1 second, pausing
for 2 seconds and then ashing four times, pausing for 3 seconds.
Over-current protection: The green light repeats in a cycle of ashing once in 1 second, pausing
for 2 seconds and then ashing ve times, pausing for 3 seconds.
Battery temperature is too high: The green light repeats in a cycle of ashing twice in 1 second,
pausing for 2 seconds and then ashing three times, pausing for 3 seconds.
Battery temperature is too low: The green light repeats in a cycle of ashing twice in 1 second,
pausing for 2 seconds and then ashing four times, pausing for 3 seconds.
Contactor-related failures: The green light repeats in a cycle of ashing three times in 1 second,
pausing for 2 seconds and then ashing four times, pausing for 3 seconds.
The yellow light ashes rapidly in 1 second when other failures happen.
•
•
•
•
•
•
•
•
When powered o, if the green light of power indicator is always on, it means that the battery
is in a balanced state, which is a normal phenomenon.
