EP Equipment EPL152 - Truck Dimensions and Performance; Truck Dimensions; Additional Performance Data

REV. 03/2020
7
E
3.2 Tyre size, driving
wheels(diameter×width)
mm Ф210x70 Ф210x70
3.3 Tyre size, loading
wheels(diameter×width)
mm Ф80x60(
Ф74x88)
Ф80x60(
Ф74x88)
3.4 Tyre size, caster
wheels(diameter×width)
mm Ф74x30 Ф74x30
3.5 Wheels, number driving,
caster/loading (x=drive
wheels)
mm 1x,2/4(1x,2/2) 1x,2/4(1x,2/2)
3.6 Track width, front,driving
side
b10 mm 450 450
3.7 Track width,rear,loading
side
b11 mm 390/(535) 410/(535)
Dimensions
4.4 Lift height h3 mm 115 115
4.9 Height drawbar in driving
position min./max.
h14 mm 700/1260 750/1190
4.15 Lowered height h13 mm 80 80
4.19 Overall length l1 mm 1550 1580
4.20 Length to face of forks l2 mm 400 425
4.21 Overall width b1/ b2 mm 610(695) 685
4.22 Fork dimensions s/ e/ l mm 50x150x1150 50x150x1150
4.25 Distance between fork-
arms
b5 mm 540(685) 560(685)
4.32 Ground clearance, center
of wheelbase
m2 mm 30 30
4.34.1 Aisle width for pallets 1000
× 1200 crossways
Ast mm 2145 2175
4.34.2 Aisle width for pallets 800
× 1200 lengthways
Ast mm 2050 2080
4.35 Turning radius Wa mm 1330 1360
Performance data
5.1 Travel speed, laden/
unladen
km/ h km/h 4/4.5 4.5/5
5.2 Lifting speed, laden/
unladen
m/ s 0.028/0.031 0.02/0.024
