ep EPL154 - Page 26

REV. 09/2020
B8
1
2
3
4
5
6
7
WPL201
8
9
Low Voltage Protection for EPL151/
EPL154/EPL185/WPL201
Thecarhaslowvoltageprotectionfunction.
When the battery power of forklift truck is 7%-
15%.thedisplayscreenshowsL1(onlyfor
WPL201).Atthistime,theforklifttruckcan
notliftgoods,butitcanrunnormally.When
thebatterypowerislessthan7%.thedisplay
screenshowsL2(onlyforWPL201).Atthis
time, the forklift can not be lifted and the
drivingspeedbecomesslower.
i
NOTE
• LED (1) displays the remaining charge;
• LED (9) indicate the the acceleration status
of the accelerator.
• LED (2) indicate fault warning;
• LED(3) indicate charging status, when it
show a battery sign, you shoud charge;
• LED (4) indicate emergency reverse switch
status;
• LED (5) indicate truck stop or walk, if the
truck stop display"P", if the truck travel
display"N";
• LED (6) indicate turtle speed status;
• LED (7) indicate rise and fall indication.
• LED (8) indicate the operating hours.
WARNING
when the LED(1)signshowred.please
chargethebatteryintime.
LCD (1) displays the state of charge;
DISPLAY DESCRIPTION
Continuous red Charge is charging
Continuous green Battery charging is
complete
The LCD (2) remain green light lit under
normal, ashing show the failure state of
truck.
HPL152
右视图
Right
1
2
