B9
If the controller detects a battery failure, ashes of LCD
（
3
）
represent battery failure information
until the failure is remedied. Details of failure information are shown as below:
Under-voltage of single cell battery: The green light repeats in a cycle of ashing once in 1
second, pausing for 2 seconds and then ashing twice, pausing for 3 seconds.
Over-voltage of single cell battery: The green light repeats in a cycle of flashing once in 1
second, pausing for 2 seconds and then ashing three times, pausing for 3 seconds.
Short circuit protection: The green light repeats in a cycle of ashing once in 1 second, pausing
for 2 seconds and then ashing four times, pausing for 3 seconds.
Over-current protection: The green light repeats in a cycle of ashing once in 1 second, pausing
for 2 seconds and then ashing ve times, pausing for 3 seconds.
Battery temperature is too high: The green light repeats in a cycle of ashing twice in 1 second,
pausing for 2 seconds and then ashing three times, pausing for 3 seconds.
•
•
•
•
•
The LCD display (3) show battery residual
capacity.
The color of the LCD (3) represent the
following conditions:
Component LCD color
Residual
capacity
Standard
battery
residual
capacity
Green 30-100%
Continuous
Yellow
15-30%
Slow
ashing red
light(Flashing
period 2s)
7-15%
Quick ashing
red light
(Flashing
period 1s)
0-7%
Aftertheredlightstartsflashing,thebatterywillenterthelow-voltageprotectionstate.
Accordingtothebatterystate,Thetruckwillappearaccidentalpower-oprotection.
i
3
NOTE
After the yellow light is lit, The residual capacity of the turk is less chan 30
%
.Theresidual
capacity is less than 17
%
,
The truck only travel at the low speed.
Itmustchargethebattery
immediatelytoavoidtruckpoweroorshortenthelifeofbattery.
WARNING
