ep EST122 - Dimensions and Tyre Specifications

REV. 12/2020
2
E
3.2 Tyre size, driving
wheels(diameter×width)
mm Ø210×70
3.3 Tyre size, loading
wheels(diameter×width)
mm Ø74×72
3.4 Tyre size, caster
wheels(diameter×width)
mm Ø130×55
3.5 Wheels, number driving,
caster/loading (x=drive
wheels)
mm 1x +1/4
3.6 Track width, front,driving
side
b10 mm 531
3.7 Track width,rear,loading
side
b11 mm 405
Dimensions
4.2 Height, mast lowered h1 mm 1956
4.3 Free lift h2 mm
/
4.4 Lift height h3 mm 2630
4.5 Height, mast extended h4 mm 3271
4.9 Height drawbar in driving
position min./max.
h14 mm 750/ 1340
4.10 Height of wheel arms /
4.15 Lowered height h13 mm 85
4.19 Overall length l1 mm 1713
4.20 Length to face of forks l2 mm 563
4.21 Overall width b1/
b2
mm 792
4.22 Fork dimensions s/ e/
l
mm 60/ 170/ 1150
4.24 Fork carriage width b3 mm 680/770
4.25 Distance between fork-
arms
b5 mm 570/685
4.26 Distance between wheel
arms
/
4.31 Ground clearance, laden,
below mast
m1 /
