ep EST122 - Electric Engine and Battery Data

REV. 12/2020
3
E
4.32 Ground clearance, center of
wheelbase
m2 mm 25
4.34.1 Aisle width for pallets 800 ×
1200 lengthways
Ast mm 2224
4.34.2 Turning radius Wa mm 2158
4.35 Turning radius Wa mm 1390
Performance data
5.1 Travel speed, laden/ unladen km/ h km/h 4.2 /4.5
5.2 Lifting speed, laden/ unladen m/ s 0.10/0.14
5.3 Lowering speed, laden/
unladen
m/ s 0.10/0.10
5.8 Max. gradeability, laden/
unladen
% 4/10
5.10 Service brake type Electromagnetic
Electric-engine
6.1 Drive motor rating S2 60 min hp kW 0.75
6.2 Lift motor rating at S3 15% hp kW 2.2
6.3 The maximum allowed size
battery
in. mm 260x165x210
6.4 Battery voltage/nominal
capacity K5
V/ Ah 2x12/85
6.5 Battery weight lb. kg 2x24
Addition data
8.1 Type of drive control DC
10.5 Steering type Mechanical
10.7 Sound pressure level at the
driver’s ear
dB (A) 74
