ep WPL201 - Charging the Battery with External Charger

REV. 09/2020
C7
•Inspect whether relevant charging requirements are satised according to “3.2.1
precautions”;
•
Park the truck securely as described chapter B Section1.2.6;
•
Remove the battery
；
(see section 1.2)
•
Plug into charging stand and charge;
•
The LED light on the charging stand comes on.
A fully charging time see described in paragraph 1.2.4.
EPL151 WPL201
LED light mode on the charging stand
• Charging:red LED light
• Fully charged:green LED light
•Chargingfault:ashingyellowLEDlight
• Battery fault:steady yellow LED light
Correctly plug the battery into the
chargingstand.
HPL152
i
NOTE
i
NOTE
1.1.3 Charging the battery with external charger
