Battery Voltage Control Parameters
Below parameters are measured in the 12V system at 25 ºC; please double
the values in the 24V system
Battery Type
Sealed
Gel
Flooded
Over Voltage Disconnect Voltage
16.0V
16.0V
16.0V
Charging Limit Voltage
15.0V
15.0V
15.0V
Over Voltage Reconnect Voltage
15.0V
15.0V
15.0V
Equalize Charging Voltage
14.6V
——
14.8V
Boost Charging Voltage
14.4V
14.2V
14.6V
Float Charging Voltage
13.8V
13.8V
13.8V
Boost Reconnect Charging Voltage
13.2V
13.2V
13.2V
Low Voltage Reconnect Voltage
12.6V
12.6V
12.6V
Under Voltage Warning Reconnect
Voltage
12.2V
12.2V
12.2V
Under Voltage Warning Voltage
12.0V
12.0V
12.0V
Low Voltage Disconnect Voltage
11.1V
11.1V
11.1V
Discharging Limit Voltage
10.6V
10.6V
10.6V
Equalize Duration
120 min.
——
120 min.
Boost Duration
120 min.
120 min.
120 min.
7. Protection
 Battery Over Voltage Protection
When the battery voltage reaches the Over Voltage Disconnect
Voltage(OVD), the controller stops charging the battery to protect the
battery from being overcharged.
 Battery Over Discharge Protection
When the battery voltage reaches the Low Voltage Disconnect
Voltage(LVD), the controller stops discharging the battery to protect the
battery from being over-discharged.
 Overload Protection
The load is switched off after a delay when the load current exceeds 1.25
times the rated current. The user must reduce the load appliance, press the
button, or restart the controller.
 Load Short Circuit Protection
The load is switched off when the load short circuit (≥3 times the rated
current) happens. The user must clear the short circuit faults, press the
button, or restart the controller.
 High Voltage Transients Protection
The controller is protected against small high voltage transients. In
lightning-prone areas, an external lightning arrester is recommended.
8. Troubleshooting
Faults
Possible
reasons
Troubleshooting
The charging LED
turns off during the
daytime when
sunshine falls on PV
modules properly.
PV array
disconnection
Confirm that PV and battery
wire connections are correct
and tight.
No LED indicator
Battery voltage
may be less than
8V
Measure battery voltage with
the multi-meter. Min.8V can
start up the controller.
Charging LED fast
flashes.
Battery over
voltage
Check if the battery voltage is
higher than the OVD, and
disconnect the PV.
LED1 fast flashes.
Battery
over-discharged
The load will recover when the
battery voltage is restored to or
above the LVR (low voltage
reconnect voltage).
Load LED flashes
slowly.
Overload

① Please reduce the number
of electric equipment.
② Press the button or restart
the controller.
Load LED fast
flashes.
Load short circuit
① Check carefully loads
connection, clear the fault.
② Press the button or restart
the controller.
When the load current exceeds 1.25 times, 1.5 times, and 2 times the rated
value, the controller can automatically turn off loads after 60s, 5s, and 1s,
respectively.
10. Disclaimer
This warranty does not apply under the following conditions:
 Damage from improper use or use in an unsuitable environment.
 PV or load current, voltage, or power exceeds the controller's rated value.
 User disassembly or attempted to repair the controller without permission.
 The controller is damaged due to natural elements such as lighting.
 The controller is damaged during transportation and shipment.
9. Technical Specifications
Item
LS0512E
LS1012E
LS1024E
LS2024E
LS0512EU
LS1012EU
LS1024EU
LS2024EU
LS3024EU
Nominal system
voltage
12VDC
12/24VDC Auto
12VDC
12/24VDC Auto
Rated charge current
5A
10A
20A
5A
10A
20A
30A
Rated discharge
current
5A
10A
20A
5A
10A
20A
30A
Battery input voltage
range
8V～16V
8V～32V
8V～16V
8V～32V
Max. PV open circuit
voltage
30V
50V
30V
50V
Self-consumption
12V≤5mA; 24V≤7mA
Charge Circuit
Voltage Drop
≤0.21V
≤0.13V
Discharge Circuit
Voltage Drop
≤0.12V
≤0.17V
USB input interface
—
5VDC/1.2A
5VDC/2A
Temperature
compensation
coefficient
-5mV/℃/2V
Environment
temperature
-35℃ ～ +50℃
Humidity
≤95%,(N.C.)
Enclosure
IP30
IP20
Grounding
Common Positive
Dimension(L x W x H)
92.8x65
x20.2mm
101.2x67
x21.8mm
101.2x67
x21.8mm
128x85.6
x34.8mm
109.7x65.5
x20.8mm
120.3x67
x21.8mm
120.3x67
x21.8mm
148x85.6
x34.8mm
148x106.8
X43.7mm
Mounting size
84.4mm
92.7mm
92.7mm
118mm
100.9mm
111.5mm
138mm
Mounting hole size
Φ4.5
Terminals
14AWG/2.5mm
2
12 AWG/4mm
2
12AWG/4mm
2
10AWG/6mm
2
14AWG/2.5mm
2
12AWG/4mm
2
12AWG/4mm
2
10AWG/6mm
2
8AWG/10mm
2
Net weight
0.07kg
0.08kg
0.08kg
0.15kg
0.09kg
0.10kg
0.10kg
0.18kg
0.29kg
Any changes without prior notice! Version number: V4.2
