CP4B Room Thermostat
When the thermostat is in the AUTO mode, it will operate according
to the times and temperatures that have been programmed. The user
can select from 6 dierent programs per day, each with a time and a
temperature.
There is no OFF time, only a higher and a lower temperature setpoint.
If the user does not want the thermostat to operate, set the
temperature for this time to be a low temperature. The thermostat
will turn ON if the room temperature is lower than the setpoint for the
current period.
Example: If P1 is set to be 21˚C at 6am, and if P2 is set to be 10˚C at
8am, the thermostat will look for the temperature to be 21˚C between
6am and 8am.
