EPH Controls EMBER - LCD, LED, and Button Legend; Gateway LED Status Indicators; Gateway Button Functions

5
LCD / LED / Button legend
WPS / Smartlink
button
Function
button
Reset
button
Figure 1: The gateway
Figure 2: The RF receiver
Buttons to be used during gateway installation
WPS / SmartlinkFunction
Power
SupplyReset
LED Status
Red LED on Gateway has power
Green LED on Gateway connected to WiFi
White LED on Gateway connected to receiver
