EPH Controls R17 - Wiring Diagram

4
R17
V2
[1]
[7]
[2]
[6]
[3]
[4]
[5]
[1] Displays current time.
[2] Displays current day of the week.
[3] Displays zone title.
[4] Displays current mode.
[5] Displays when keypad is locked.
[6] Displays when frost protection is activated.
[7] Displays current date.
LCD Display
