HB
3100, 3100 DP, 3600, 3600 DP, 4100, 4100 DP, 4700, 4700 DP
Safety and operating instructions
Hydraulic breakers
© Construction Tools GmbH | 3390 5203 01 | 2019-08-06
Original Instructions

Table of Contents

Questions and Answers

  • S
    Steven TaylorAug 13, 2025
    Why is my Epiroc HB 4700 Industrial Equipment hydraulic breaker operating too slowly?
    • J
      Julie TaylorAug 13, 2025
      If your Epiroc Industrial Equipment hydraulic breaker is operating too slowly, the issue might stem from several factors. Begin by checking the engine speed and/or mode stage of the carrier, as well as the operating pressure, and make any necessary adjustments. Ensure that the connecting fitting in the pressure and tank line is securely tightened. Verify that the shut-off valve in the pressure and/or tank line is fully open. Inspect the oil filter and oil cooler for excessive flow resistance, cleaning or replacing them as needed. Lastly, confirm that the gas pressure in the piston accumulator isn't too high; if it is, release some gas.
  • T
    Tiffany LeeAug 17, 2025
    How to fix low impact force on Epiroc HB 4700 Industrial Equipment?
    • J
      joebrownAug 17, 2025
      To address a low impact force issue on your Epiroc Industrial Equipment, begin by checking the gas pressure. If the gas pressure is too low fill the piston accumulator. Also, check the pump of the hydraulic installation to ensure it delivers sufficient oil; if it doesn't, compare its characteristic with a measuring device to the original details and renew the pump if required.
  • C
    Casey BuckAug 22, 2025
    What to do if oil leaks from ports »P« und »T« in Epiroc Industrial Equipment?
    • J
      Juan PenningtonAug 22, 2025
      If oil is leaking from ports »P« and »T« on your Epiroc Industrial Equipment, check the cap nuts and tighten them. Also, if the hose connection CL to port »P« for ContiLube® II or the plug is loose and ContiLube® II has not been installed, check the cap nuts and plugs and tighten them.
  • K
    Kevin JohnsonAug 27, 2025
    Why is the impact rate too high and impact force too low in Epiroc Industrial Equipment?
    • J
      John AdamsAug 27, 2025
      If the impact rate is too high and the impact force is too low in your Epiroc Industrial Equipment, check the gas pressure and fill the piston accumulator, as there may be no gas in the piston accumulator.
  • J
    James ThompsonSep 1, 2025
    What to do if oil escapes between the cylinder cover and the cylinder of Epiroc HB 4700?
    • D
      debra03Sep 1, 2025
      If oil is escaping between the cylinder cover and the cylinder of your Epiroc Industrial Equipment, it could be due to loose tensioning bolts. Check the tensioning bolts and tighten them. Alternatively, the seals might be damaged, in which case you should replace them.
  • J
    James HolmesNov 7, 2025
    What to do if Epiroc HB 4700 hydraulic breaker does not start?
    • C
      carriestewartNov 7, 2025
      If your Epiroc Industrial Equipment hydraulic breaker doesn't start, several issues could be the cause. First, ensure the pressure and tank lines aren't swapped and are correctly connected. Next, check that the shut-off valve in the pressure and/or tank line is open. Also, verify that the gas pressure in the piston accumulator isn't too high, and adjust if necessary. Check that the oil level in the tank is adequate and top up if low. Inspect couplings for defects and replace any faulty ones. Examine the electrical system for faults and correct them. If the magnet on the switch-on valve is damaged, replace it. Ensure the operating pressure isn't too low by checking the carrier engine speed, pump delivery, and pressure relief valve, adjusting settings or replacing parts as needed. Finally, c...

Summary

Introduction to Hydraulic Breaker Operation

Understanding Safety and Operating Instructions

Explains the aim of the instructions and the meaning of symbols used.

Hydraulic Breaker Safety Precautions

Decoding Safety Signal Words

Operator Qualification for Hydraulic Breakers

Specifies required qualifications for transport, installation, operation, and repair.

Proper Use and Prohibited Operations

Details correct applications and actions to avoid, preventing damage and injury.

Essential Personal Protective Equipment (PPE)

Lists mandatory PPE for operating the hydraulic breaker to prevent injury.

Carrier and Transport Safety Guidelines

Hydraulic System Installation Safety

Details safety measures for hydraulic connections, pressure, and special parts like accumulators.

Media Handling and Hazard Precautions

Environmental, Falling, Emission, and Handling Hazards

Safety in Repair, Modifications, and Environmental Impact

Safe Transport Procedures for Hydraulic Breakers

Hydraulic Breaker Installation Guide

Adapter Plate Manufacturing and Installation

Attaching Breaker to Carrier Mechanism

Details mechanical mounting and hydraulic connection procedures.

Hydraulic Breaker Operation Procedures

Initial and Long-Term Storage Operation

Preparations and Functional Testing

Steps for preparing the breaker and performing a functional test.

Proper Hydraulic Breaker Usage Techniques

Guidelines on working angle, advance, and impact time for optimal use.

Operating in Temperature Extremes & Prohibited Actions

Instructions for high/low temperatures and actions to avoid.

AutoControl, IPS, and PowerAdapt Systems

Hydraulic Breaker Maintenance Schedule and Procedures

Hydraulic Breaker Maintenance Checklist

A schedule of maintenance tasks based on operating hours and time intervals.

Safely Depressurizing Hydraulic Systems

Detailed steps for safely releasing pressure in the hydraulic system.

Hydraulic Breaker Lubrication Guide

Covers checking lubricant film, automatic/manual lubrication, and paste filling.

Checking Breaker Components for Wear

Piston and HP Accumulator Checks

Checking Hydraulic Lines, Filter, and Adapter Plate

Tightening Torques for Bolt Connections

Hydraulic Breaker Troubleshooting Guide

Troubleshooting: Breaker Fails to Start

Troubleshooting: Slow Breaker Operation

Troubleshooting: Impact Force and Rate Problems

Troubleshooting: Oil Leaks from Various Points

Troubleshooting: Temperature and Pressure Problems

Hydraulic Breaker Repair and Sending for Service

Safety Precautions for Hydraulic Breaker Repair

Warns against non-professional disassembly and advises contacting support.

Hydraulic Breaker Storage Guidelines

Hydraulic Breaker Technical Specifications

Epiroc HB 4700 Specifications

General IconGeneral
BrandEpiroc
ModelHB 4700
CategoryIndustrial Equipment
LanguageEnglish
