Hardware description of the Centrifuge 5810/5810 R
General design
The centrifuges of the series 58XX consist of the following main electrical assembly groups:
– Assembly group "Control" with input filter, power supply unit, central control unit, frequency
converter interface, drive and position recognition of the lid locking mechanism, connections for
imbalance monitoring and rotational speed monitoring. For the refrigerated version there are also
the temperature monitoring and the elements to control the condenser fan, refrigeration aggregate
and motor fan.
– Assembly group "Display/Operation" consisting of the keypad (snap washer under the foil),
LCD display module incl. driver and background illumination and signal transmitter.
– Assembly group imbalance monitoring consisting of a PCB with an analogue Hall sensor and
OpAmp. for signal processing.
– Frequency converter CCI 1000 of the Hanning company to operate a 3-phase asynchronous motor.
– 3-phase asynchronous motor.
– For the refrigerated version:
Refrigeration aggregate, condenser fan, motor fan.
– For the non-refrigerated version:
Lifting magnet to open an additional ventilation flap when using fixed-angle rotors.
– As an option we offer a PC interface, that can be retrofitted in the form of a plug-in module and an
interface cable.
– Various cables.
