Error lists/Troubleshooting 3-19
Centrifuge 5804/5804 R and 5810/5810 R
3 Error lists / Troubleshooting
3: FC parameters – temperature during a run
xxx – temperature frequency converter
FC – oldxxx =digital value displayed
(switching off at 128, value for 20 °C = approx. 83)
FC – newxxx =display in °C x factor 10
(switching off at approx. 75 °C, display for 20 °C = 200)
* – FC temperature warning
yyy – parameter 4: acceleration ramp (for factory checks only)
zzz – parameter 5:braking ramp (for factory checks only)
4: Rotor recognition
xxx – Rotor relation (rotor table, rotor relations, see last page of Section 3)
y – number of recognition measurements
zz – Rotor number (rotor table, rotor relation, see last page of Section 3)
5: Imbalance monitoring
xxx – Imbalance value (current sensor idle value during standstill)
Recommended service setting = 670 ± 30
Please note, important!
Max. tolerance during standstill = 670 ± 100
Please note, important!
zzz – saved idle value of sensor (from last imbalance calibration)
with lid opened
5: Imbalance monitoring
with lid closed
xxx – Imbalance value (current sensor idle value during standstill)
Recommended service setting = 670 ± 30
Please note, important!
Max. tolerance during standstill = 670 ± 100
Please note, important!
xxx – imbalance value during run = current sensor value (cannot be evaluated during a run)
yyy – maximum appeared imbalance (only active during run)
zzz – imbalance cut-off value for the rotor used
3: xxx*yyy zzz
4: xxx y zz
5: xxx ru=zzz
5: xxx yyy zzz
MSTM/0408
